Ajax MotionProtect Outdoor Jeweller

MotionProtect Outdoor Jeweller: Outdoor Security with Intelligent False Alarm Filtering

MotionProtect Outdoor Jeweller is a wireless outdoor motion detector equipped with intelligent algorithms and advanced sabotage protection. Designed to withstand harsh weather and environmental challenges, it delivers accurate intrusion detection while ignoring wind-blown vegetation, pets, and common outdoor interferences. With long battery life, anti-masking, and Ajax’s robust Jeweller communication technology, it ensures reliable outdoor security with minimal maintenance.

Built to Withstand the Outdoors, Smart Enough to Ignore the Noise

Equipped with dual PIR sensors and the advanced LISA algorithm, MotionProtect Outdoor precisely detects human movement and filters out anything that shouldn’t trigger an alarm.

• LISA Algorithm: Dual-stage digital signal analysis compares waveforms and spectral signatures to confirm human motion while ignoring swaying trees, shadows, insects, or birds.
• Pet Immunity: Ignores animals up to 80 cm in height, so pets can roam freely without causing false alarms.
• Adjustable Detection Range: Detection distance is adjustable from 3 to 15 meters using a built-in scrollbar.
• Wide Horizontal Angle: A 90° detection field ensures wide area coverage.
• Temperature Compensation: Maintains accuracy across a wide range of conditions, from -25°C to +60°C.

Advanced Sabotage Protection for Critical Outdoor Zones

MotionProtect Outdoor delivers top-tier protection against tampering and attempts to disable the detector—keeping your perimeter secure, 24/7.

• Anti-Masking System: Detects attempts to obscure lenses with paint, tape, or other materials—even when the system is disarmed.
• Tamper Alarm: Triggers instantly if the device is opened or removed from the SmartBracket.
• Spoofing Protection: Each device is authenticated during every session with the hub to block unauthorized access or imitation.
• Communication Loss Alerts: Notifies users and monitoring centers within 36 seconds if the device goes offline.

Wireless, Weatherproof, and Always Ready

MotionProtect Outdoor is engineered to withstand the elements while offering a seamless, wire-free installation experience.

• IP55 Rated Housing: Protected against dust and water jets, making it suitable for all weather conditions.
• Wide Temperature Range: Operates in extreme cold and heat, from −25°C to +60°C.
• Install Anywhere: Mounts at a height of 0.8–1.3 meters using the SmartBracket—ideal for gardens, gates, driveways, and perimeter fencing.
• Pre-Installed Batteries: Comes ready to go, with up to 5 years of battery life using two CR123A batteries.

Reliable, Encrypted Communication with Jeweller Technology

Ajax’s proprietary Jeweller radio protocol ensures instant and secure data transmission, even over long distances.

• Up to 1,700 m Range: In open space, the detector maintains a stable connection with the hub or range extender.
• Two-Way Encrypted Communication: Data is protected with AES-based block encryption using dynamic keys.
• Frequency Hopping: Automatically changes channels to prevent jamming or interference.
• Remote Configuration: Adjust settings and test performance remotely via Ajax PRO apps.

Tech Specs

• Classification: Electro-optical wireless outdoor motion detector
• Type: Wireless
• Installation Method: Outdoors / Indoors
• Compatibility: Works with Hub, Hub Plus, and ReX
• Sensitive Elements: 2 × PIR sensors
• Detection Distance: Adjustable, 3–15 m
• Detection Angle: 90° horizontal
• Detection Speed: 0.3 to 2.0 m/s
• Recommended Installation Height: 0.8–1.3 m
• Pet Immunity: Up to 80 cm height
• Temperature Compensation: Yes
• False Alarm Prevention: LISA, SmartDetect algorithms
• Tamper Alarm: Yes
• Anti-Masking System: Yes (24/7 active)
• Communication Technology: Jeweller
• Communication Range: Up to 1,700 m (open space)
• Radio Frequency Bands: Region-dependent (e.g., 868.0–868.6 MHz)
• Encryption: AES block encryption with dynamic key
• Polling Interval: 12–300 s
• Power Supply: 2 × CR123A batteries (pre-installed)
• Battery Life: Up to 5 years
• External Power Input: 5–28 V DC, 200 mA
• Operating Voltage Range: 2.1–3.3 V
• Operating Temperature: −25°C to +60°C
• Humidity: Up to 95%
• Protection Class: IP55
• Dimensions: 183 × 70 × 65 mm
• Weight: 322 g
• Colors Available: White,Black
• Certification: EN 50131, CU TR 020/2011, EAC
• Warranty: 24 months (excluding batteries)

MotionProtect Outdoor Jeweller is your first line of defense, purpose-built to secure your property’s perimeter. With powerful false alarm filtering and proven outdoor durability, it ensures that only real threats are reported—giving you peace of mind, rain or shine.
