Ajax NVR

Ajax NVR - Network Video Recorder

Perfectly Integrated with Ajax Security Systems

The Ajax NVR provides a seamless solution for video surveillance with Ajax’s advanced security systems, combining speed, high-resolution video verification, and professional-grade security features. It integrates effortlessly with IP cameras and delivers ultra-fast access to video archives, ensuring that security professionals can respond to incidents in real-time, both on mobile and desktop.

Key Features

High-Resolution Alarm Verification

• Instantly verify alarms with high-definition video. With ONVIF and RTSP support, Ajax NVR ensures that you receive crisp video footage for every triggered event. Motion detection settings can be customized either through the NVR or camera, based on your preferences.

In-App Video Management System

• Videowall: Combine live video feeds from all connected cameras for a comprehensive overview of your property.
• Event Filters & Timeline: Smooth timeline previews and the ability to filter events make it easier to track specific incidents.
• Visual Verification of Ajax Alarms
  Set up scenarios in which Ajax detectors automatically trigger specific cameras to record and provide immediate visual verification of alarms through both mobile and desktop apps.
• Dual Streaming for Fast Archive Navigation
  Ajax NVR supports dual streaming technology for fast, lag-free video viewing. Access archived footage instantly, jump directly to specific timestamps, and export files with ease.
• Built-In Motion Detection
  The NVR includes motion detection software to ensure that recordings are only triggered when there’s actual movement, conserving storage space.

Privacy and Security

• Multi-tiered account security, including two-factor authentication, session control, and biometric login options.
• Restricted Data Access: Control who can view, save, or manage video streams with the Privacy tab, providing full user access management.
• Secure Video Export: Videos exported from the NVR include a digital signature for authenticity and integrity verification, ensuring that evidence is tamper-proof.

Technical Specifications

• Compatibility:
• Hub Models: Hub, Hub Plus, Hub 2 (2G/4G), Hub 2 Plus, Hub Hybrid (2G/4G)
• IP Cameras: ONVIF (Profile S/T) & RTSP
• NVR Models: 8-channel, 16-channel (up to 4K resolution, 25/30 FPS)
• Storage::Compatible with SATA HDDs (3.5”) up to 16 TB (HDD not included).
• H.265/H.264 Decoding Formats
• Bandwidth:Supports up to 100 Mbps for fast data transmission.
• Power Supply Main: 110–240 V~, 50/60 Hz, 0.6 A (up to 24W)
• Backup: CR2032 battery (3V) for system clock
• Communication Channels::Ethernet: Up to 100 Mbps
• Bluetooth: BLE frequency band 2.400–2.4835 GHz
• Radio Signal Power:2.5 mW (100 mW limit)
• Protection Class:IP20 (indoor use only)
• Dimensions:251 × 251 × 51 mm (9.88" × 9.88" × 2.01")
• Weight::700 g (24.69 oz) (without HDD)
• Operating Temperature Range:0°C to +40°C (32°F to 104°F)
• Operating Humidity:Up to 75%

NVR Product Versions

• NVR (8-ch): 8-channel NVR
• NVR (16-ch): 16-channel NVR
• NVR DC (8-ch): 8-channel NVR, powered by low-voltage DC
• NVR DC (16-ch): 16-channel NVR, powered by low-voltage DC

Additional Features

• Tamper Alarm: Notifications when the device is tampered with or removed from its mounting.
• Fanless Design: Ensures quiet operation and greater reliability in environments where noise and dust are concerns.
• Customizable Video Wall: Rearrange tiles on your Videowall for simultaneous monitoring of live feeds from your cameras on both mobile and desktop apps.
• Archive Synchronization: Archive events are synchronized with system events for easy navigation and retrieval.
• Advanced Video Streaming: The JetSparrow technology offers ultra-fast video streaming with peer-to-peer transmission and TLS encryption, ensuring data security during transmission.

Complete Set Includes:

• Ajax NVR
• SmartBracket Mounting Panel
• Power Cable
• Ethernet Cable
• Installation Kit
• Quick Start Guide
• Warranty: 24 months

Installation and Setup

• QR Code Pairing: Easily pair with Ajax security systems using the QR code.
• No Need for Disassembly: SmartBracket panel allows for quick mounting without the need to open the enclosure.
• Mobile and Desktop Setup: Complete installation and configuration via Ajax apps, ensuring real-time system monitoring and alerts.

Security and Compliance

Ajax NVR is NDAA-compliant and features cybersecurity testing to ensure its safety and integrity. All system data is stored within the European Union, adhering to strict European data protection standards.

Conclusion

Ajax NVR offers a future-proof and highly customizable solution for video surveillance and system security, ensuring real-time video verification, streamlined archive navigation, and superior data protection for both professional and personal use. Integrating seamlessly with Ajax cameras and hubs, it delivers an exceptional video management experience that professionals trust.
